This is the one single brake disc. If you plan to change discs on the entire axle then you should buy two products.
Dimensions and size
| Brake Disc Thickness | 26 | mm |
| Centering Diameter | 71 | mm |
| Height | 46 | mm |
| Minimum thickness | 23 | mm |
| Outer Diameter | 300 | mm |
The special shape of the grooves on Brembo® Max™ discs developed for outstanding braking performance in all conditions, especially on slick surfaces. The unique design optimizes road performance of Brembo® Max™ brake discs, quickly restores the optimum braking conditions and ensures continuous renewal of the friction material. Brembo® Max disc is a perfect product for the enthusiast who needs more responsive brake pedal and highly efficient braking.
Specifications
| Brake Disc Type | internally vented |
| Brake Disc Type | Slitted |
| Number of Holes | 5 |
| Machining | High-carbon |
| Surface | Coated |
| Tightening Torque | 110 Nm |
Shipping Details
| Weight | 8.802 Kg |
| Customs Code | 870830 |
| Country of Origin | Italy |
€69.20
- Price Includes VAT 0%
- Dispatch on next business day
- Check shipping rates
- Easy returns
Shipping rates
Reference Numbers
OE Numbers
BUICK (SGM)
CHEVROLET (SGM)
Cross-Reference Numbers
AP
X 25321
BOSCH
BUICK (SGM)
13502052
CHEVROLET
13502051
13502052
13503988
23118275
CHEVROLET (SGM)
13502052
DELPHI
FEBI BILSTEIN
MEYLE
MINTEX
OPEL
13502051
13502052
13503988
23118060
569070
569076
569082
569098
95527031
PAGID
55056
QUINTON HAZELL
BDC5934
MBD5934
TRW
VAUXHALL
13502051
13502052
13503988
23118060
95527031
sbs
1815205015
1815315015
Fit Vehicles
CHEVROLET
36 vehicles
CRUZE
2009 - ...
| Body | Model | Produced | KW | HP | CCM |
|---|---|---|---|---|---|
| CRUZE (J300) 1.6 | 2009-05 - ... | 91 | 124 | 1598 | |
| CRUZE Station Wagon (J308) 1.4 | 2012-08 - ... | 103 | 140 | 1364 | |
| CRUZE Station Wagon (J308) 1.7 TD | 2013-11 - 2015-12 | 81 | 110 | 1686 | |
| CRUZE Station Wagon (J308) 1.4 | 2013-07 - 2015-12 | 74 | 101 | 1398 | |
| CRUZE Hatchback (J305) 1.7 D | 2012-01 - 2015-12 | 96 | 131 | 1686 | |
| CRUZE Hatchback (J305) 1.8 | 2011-06 - ... | 104 | 141 | 1796 | |
| CRUZE Hatchback (J305) 2.0 CDI | 2011-06 - ... | 120 | 163 | 1998 | |
| CRUZE Hatchback (J305) 1.7 TD | 2013-08 - 2015-12 | 81 | 110 | 1686 | |
| CRUZE (J300) 1.4 | 2013-07 - ... | 74 | 101 | 1398 | |
| CRUZE (J300) 1.4 | 2010-09 - ... | 103 | 140 | 1364 | |
| CRUZE Hatchback (J305) 1.4 | 2013-07 - 2015-12 | 74 | 101 | 1398 | |
| CRUZE Hatchback (J305) 1.6 | 2012-12 - ... | 86 | 117 | 1598 | |
| CRUZE Hatchback (J305) 1.8 LPG | 2011-06 - 2015-12 | 104 | 141 | 1796 | |
| CRUZE Hatchback (J305) 1.4 | 2012-06 - ... | 103 | 140 | 1364 | |
| CRUZE Hatchback (J305) 1.6 | 2011-06 - ... | 91 | 124 | 1598 | |
| CRUZE (J300) 2.0 CDI | 2010-08 - ... | 120 | 163 | 1998 | |
| CRUZE Station Wagon (J308) 1.7 TD | 2012-08 - ... | 96 | 131 | 1686 | |
| CRUZE Station Wagon (J308) 2.0 TD | 2012-08 - ... | 120 | 163 | 1998 | |
| CRUZE Station Wagon (J308) 1.8 | 2012-08 - ... | 104 | 141 | 1796 | |
| CRUZE Station Wagon (J308) 1.6 | 2012-12 - 2015-12 | 86 | 117 | 1598 | |
| CRUZE (J300) 1.6 | 2009-05 - ... | 80 | 109 | 1598 | |
| CRUZE (J300) 1.6 | 2009-05 - ... | 83 | 113 | 1598 | |
| CRUZE (J300) 1.7 D | 2012-01 - ... | 96 | 131 | 1686 | |
| CRUZE (J300) 1.8 | 2009-05 - ... | 104 | 141 | 1796 | |
| CRUZE (J300) 2.0 CDI | 2009-05 - ... | 110 | 150 | 1991 | |
| CRUZE (J300) 2.0 CDI | 2009-05 - 2011-05 | 92 | 125 | 1991 | |
| CRUZE (J300) 1.7 TD | 2013-11 - ... | 81 | 110 | 1686 | |
| CRUZE Station Wagon (J308) 1.6 | 2012-08 - 2015-12 | 91 | 124 | 1598 | |
| CRUZE Hatchback (J305) 1.6 | 2012-01 - ... | 80 | 1598 | ||
| CRUZE (J300) 1.6 | 2012-12 - ... | 86 | 1598 |
ORLANDO
2011 - ...
| Body | Model | Produced | KW | HP | CCM |
|---|---|---|---|---|---|
| ORLANDO (J309) 1.8 | 2011-02 - ... | 104 | 141 | 1796 | |
| ORLANDO (J309) 2.0 D | 2011-02 - 2015-12 | 96 | 131 | 1998 | |
| ORLANDO (J309) 2.0 D | 2011-02 - ... | 120 | 163 | 1998 | |
| ORLANDO (J309) 1.8 LPG | 2011-06 - 2015-12 | 104 | 141 | 1796 | |
| ORLANDO (J309) 1.4 | 2012-06 - ... | 103 | 140 | 1362 |
VOLT
2011 - ...
| Body | Model | Produced | KW | HP | CCM |
|---|---|---|---|---|---|
| VOLT EV 150 | 2011-11 - ... | 111 | 151 | 1398 |
OPEL
90 vehicles
AMPERA
2011 - 2015
| Body | Model | Produced | KW | HP | CCM |
|---|---|---|---|---|---|
| AMPERA (R12) EV 150 | 2011-11 - 2015-03 | 111 | 151 | 1398 |
ASTRA
2005 - ...
ZAFIRA
2011 - 2019
VAUXHALL
1 vehicles
ZAFIRA
2013 - 2016
| Body | Model | Produced | KW | HP | CCM |
|---|---|---|---|---|---|
| ZAFIRA Mk III (P12) 1.6 CDTi (75) | 2013-02 - 2016-05 | 100 | 136 | 1598 |
