6057.00 - Brake Disc

Front Axle

This is the one single brake disc. If you plan to change discs on the entire axle then you should buy two products.

Dimensions and size

Brake Disc Thickness	10	mm
Centering Diameter	60	mm
Diameter	236	mm
Height	41	mm
Minimum thickness	7	mm
Outer Diameter	236	mm

Specifications

Test Mark	K.B.A.: 61210
Weight	3.2 kg
Fitting Position	Front Axle
Number of Holes	6
Brake Disc Type	solid

Shipping Details

Weight	5.353 Kg
Customs Code	870830
Country of Origin	Spain

€120.39

Price Includes VAT 0%
Dispatch in 28 business days
Check shipping rates

Shipping rates

Shipping to :

Estimated delivery

Rate

DHL Express

Estimated delivery : 19 February

€49.26

Reference Numbers

OE Numbers

BEDFORD

569028 90008003

OPEL

569017 569028 90008003 90086193 95526650

VAUXHALL

569017 569028 90008003 90086193 95526650

23-0071

Cross-Reference Numbers

A.P.

10129 E

10129

APEC

DSK159

ATE

24.0110-0152.1 410152 510152

BEDFORD

569028 90008003

BENDIX

333151 561142B

BOSCH

0 986 478 080

BRADI

1.3404.1.4

BREMBO

08.4250.10 08.4250.14 09.A454.11

DELPHI

BG149 BG2149

FERODO

DDF104

JAPANPARTS

DI-911

JURID

561142J

LPR

O1041P

METELLI

23-0071

MGA

D871

203605

National

NBD005

OPEL

569017 569028 90008003 90086193 95526650

PAGID

52403

QUINTON HAZELL

BDC3240

REMSA

6057.00 BDM6402.10

Schaeffler FAG

BS3240

TEXTAR

98200 0208 0 1

TRW

DF1607 DF1607BP

VALEO

186010 186186

VAUXHALL

569017 569028 90008003 90086193 95526650

23-0071

WOKING

D6057.00

ZIMMERMANN

430.1020.00 4301020

Fit Vehicles

OPEL

74 vehicles

Body	Model	Produced	KW	HP	CCM
	ASTRA H (A04) 2.0 Turbo (L48)	2005-03 - 2010-10	177	240	1998
	ASTRA H GTC (A04) 2.0 Turbo (L08)	2005-08 - 2010-10	177	240	1998

Model	Produced	KW	HP	CCM
CORSA A Hatchback Van (S83) 1.0 (F08, W5L)	1986-02 - 1989-04	33	45	993
CORSA A Hatchback Van (S83) 1.2 (F08, W5L)	1986-02 - 1989-04	33	45	1196
CORSA A Hatchback Van (S83) 1.2 (F08, W5L)	1986-02 - 1989-04	40	54	1196
CORSA A Hatchback Van (S83) 1.2 (F08, W5L)	1986-02 - 1990-07	44	60	1196
CORSA A Hatchback Van (S83) 1.3 (F08, W5L)	1986-02 - 1989-04	44	60	1297
CORSA A Hatchback Van (S83) 1.3 (F08, W5L)	1986-02 - 1989-04	51	69	1297
CORSA A Hatchback Van (S83) 1.5 D (F08, W5L)	1987-06 - 1989-04	37	50	1488
CORSA A Hatchback (S83) 1.0 (F08, M08, F68, M68)	1982-09 - 1993-03	33	45	993
CORSA A Hatchback (S83) 1.2 (F08, M08, F68, M68)	1982-09 - 1990-08	33	45	1196
CORSA A Hatchback (S83) 1.2 (F08, M08, F68, M68)	1982-09 - 1990-08	44	60	1196
CORSA A Hatchback (S83) 1.2 N (F08, M08, F68, M68)	1990-01 - 1993-03	38	52	1196
CORSA A Hatchback (S83) 1.2 S (F08, M08, F68, M68)	1982-09 - 1990-02	40	55	1196
CORSA A Hatchback (S83) 1.3 (F08, M08, F68, M68)	1985-09 - 1989-10	44	60	1297
CORSA A Hatchback (S83) 1.3 i (F08, M08, F68, M68)	1986-09 - 1990-09	44	60	1297
CORSA A Hatchback (S83) 1.3 S (F08, M08, F68, M68)	1982-09 - 1989-10	51	70	1297
CORSA A Hatchback (S83) 1.4 S (F08, M08, F68, M68)	1990-01 - 1993-03	53	72	1389
CORSA A Hatchback (S83) 1.5 D (F08, M08, F68, M68)	1987-09 - 1993-03	37	50	1488
CORSA A Hatchback (S83) 1.5 TD (F08, M08, F68, M68)	1988-03 - 1993-03	49	67	1488
CORSA A TR (S83) 1.0 (F11, M11, F19, M19)	1982-09 - 1992-09	33	45	993
CORSA A TR (S83) 1.2 N (F11, M11, F19, M19)	1985-01 - 1987-10	33	45	1196
CORSA A TR (S83) 1.2 S (F11, M11, M19, F19)	1982-09 - 1993-03	40	55	1196
CORSA A TR (S83) 1.2 S (F11, M11, F19, M19)	1982-09 - 1987-10	43	58	1196
CORSA A TR (S83) 1.3 (F11, F19, M11, M19)	1985-09 - 1987-10	44	60	1297
CORSA A TR (S83) 1.3 S (F11, M11, F19, M19)	1982-09 - 1987-10	51	70	1297
CORSA A TR (S83) 1.5 D (F11, M11, F19, M19)	1987-10 - 1992-11	37	50	1488
CORSA A Hatchback (S83) 1.4 i (F08, M08, F68, M68)	1985-01 - 1993-03	40		1389
CORSA A TR (S83) 1.5 TD (F11, M11, F19, M19)	1987-10 - 1993-03	49		1488
CORSA A TR (S83) 1.4 S (F11, M11, F19, M19)	1989-09 - 1993-03	53		1389

Model	Produced	KW	HP	CCM
KADETT D (31_-34_, 41_-44_) 1.0	1979-09 - 1982-08	30	41	993
KADETT D (31_-34_, 41_-44_) 1.0	1979-09 - 1984-08	33	45	993
KADETT D (31_-34_, 41_-44_) 1.2	1982-08 - 1984-08	40	55	1196
KADETT D (31_-34_, 41_-44_) 1.2	1979-08 - 1982-07	39	53	1196
KADETT D (31_-34_, 41_-44_) 1.2 S	1979-08 - 1984-08	44	60	1196
KADETT D (31_-34_, 41_-44_) 1.3 N	1979-08 - 1984-08	44	60	1297
KADETT D (31_-34_, 41_-44_) 1.3 S	1979-08 - 1984-08	55	75	1297
KADETT D (32_,37_,39, _42) 1.2 S	1979-08 - 1984-08	44	60	1196
KADETT D Estate (35_, 36_, 45_, 46_) 1.2	1979-08 - 1982-07	39	53	1196
KADETT D Estate (35_, 36_, 45_, 46_) 1.2 S	1979-08 - 1984-08	44	60	1196
KADETT D Estate (35_, 36_, 45_, 46_) 1.3 N	1979-08 - 1984-08	44	60	1297
KADETT D Estate (35_, 36_, 45_, 46_) 1.3 S	1979-08 - 1984-08	55	75	1297
KADETT E (T85) 1.2 (C19, D19)	1984-09 - 1986-07	40	55	1196
KADETT E (T85) 1.3 i Cat (C19, D19)	1985-09 - 1991-08	44	60	1297
KADETT E (T85) 1.3 N (C19, D19)	1984-09 - 1989-08	44	60	1297
KADETT E (T85) 1.3 S (C19, D19)	1984-09 - 1987-08	55	75	1297
KADETT E (T85) 1.4 i (C19, D19)	1990-01 - 1991-08	44	60	1389
KADETT E (T85) 1.4 S (C19, D19)	1990-01 - 1991-08	55	75	1389
KADETT E (T85) 1.5 TD (C19, D19)	1988-07 - 1991-08	53	72	1488
KADETT E Estate (T85) 1.2 (C15, C35, D15, D35)	1984-09 - 1986-07	40	55	1196
KADETT E Estate (T85) 1.3 N (C15, C35, D15, D35)	1984-09 - 1991-08	44	60	1297
KADETT E Estate (T85) 1.3 S (C15, C35, D15, D35)	1984-09 - 1987-08	55	75	1297
KADETT E Estate (T85) 1.4 i (C15, C35, D15, D35)	1990-01 - 1991-08	44	60	1389
KADETT E Estate (T85) 1.4 S (C15, C35, D15, D35)	1990-01 - 1991-08	55	75	1389
KADETT E Hatchback (T85) 1.2 (C08, C48, D08, D48)	1984-09 - 1986-07	40	55	1196
KADETT E Hatchback (T85) 1.3 i Cat (C08, C48, D08, D48)	1985-09 - 1991-08	44	60	1297
KADETT E Hatchback (T85) 1.3 N (C08, C48, D08, D48)	1984-09 - 1991-08	44	60	1297
KADETT E Hatchback (T85) 1.3 S (C08, C48, D08, D48)	1984-09 - 1987-08	55	75	1297
KADETT E Hatchback (T85) 1.4 i (C08, C48, D08, D48)	1990-01 - 1991-08	44	60	1389
KADETT E Hatchback (T85) 1.4 S (C08, C48, D08, D48)	1990-01 - 1991-08	55	75	1389
KADETT E Hatchback (T85) 1.4 S (C08, C48, D08, D48)	1989-09 - 1991-08	60	82	1389
KADETT E Hatchback (T85) 1.5 TD (C08, C48, D08, D48)	1988-07 - 1991-08	53	72	1488
KADETT E Hatchback (T85) 1.3 (C08, C48, D08, D48)	1985-01 - 1987-12	50		1297
KADETT E Estate Van (T85) 1.2 (C70, D70)	1984-09 - 1986-07	40	55	1196
KADETT E Estate Van (T85) 1.3 N (C70, D70)	1984-09 - 1989-07	44	60	1297
KADETT E Estate Van (T85) 1.4 i (C70, D70)	1990-01 - 1991-08	44	60	1389
KADETT E Combo (T85) 1.3 N (C25, D25)	1986-01 - 1989-12	44	60	1297
KADETT E Combo (T85) 1.3 S (C25, D25)	1986-01 - 1989-12	55	75	1297
KADETT E Combo (T85) 1.4 i (C25, D25)	1991-08 - 1994-07	44	60	1389
KADETT E Combo (T85) 1.4 S (C25, D25)	1989-07 - 1991-08	55	75	1389
KADETT E Convertible (T85) 1.3 S	1987-03 - 1993-02	55	75	1297
KADETT E Convertible (T85) 1.4 i	1990-01 - 1991-08	44	60	1389
KADETT E Convertible (T85) 1.4 S	1990-08 - 1993-02	55	75	1389
